Asus RT-N12 Series User Manual

31
Tx Power adjustment (For RT-N12 HP only)
Tx Power adjustment refers to the milliWatts (mW) needed to
power the radio signal output of the wireless router. The RT-N12
HP router can support a maximum transmission power of 200 mW.
To adjust TX Power adjustment:
1. Click Wireless on the navigation panel.
2. Click the
Professional tab.
3. On the
Tx Power adjustment item, enter a value between 0
and 200 mW.
NOTE: Increasing the Tx Power adjustment values may affect
the stability of the wireless network and the life of the wireless
router.

Asus RT-N12 Series Specifications

General

Wireless Standard	IEEE 802.11b/g/n
Frequency Band	2.4 GHz
Data Rate	Up to 300 Mbps
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Operating Temperature	0 °C to 40 °C
Antenna	2 x external antennas
Encryption	64/128-bit WEP, WPA2-PSK, WPA-PSK
Security	Firewall
Firewall	SPI
Storage Temperature	-20°C to 70°C
Storage Humidity	20% to 90% RH
