Asus RT-N12 Series User Manual

13
2. Using the bundled network cable, connect your computer to
your wireless router’s LAN port.
To set up a network using a wired connection:
1. Insert your wireless router’s AC adapter to the DC-In port and
plug it to a power outlet.
Wired connection
NOTE: Your wireless router supports both a straight-through or
crossover cable when setting up a wired connection.
RT-N12 D1

Asus RT-N12 Series Specifications

General

Wireless Standard	IEEE 802.11b/g/n
Frequency Band	2.4 GHz
Data Rate	Up to 300 Mbps
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Operating Temperature	0 °C to 40 °C
Antenna	2 x external antennas
Encryption	64/128-bit WEP, WPA2-PSK, WPA-PSK
Security	Firewall
Firewall	SPI
Storage Temperature	-20°C to 70°C
Storage Humidity	20% to 90% RH
