Asus RT-N12 Series User Manual

40
Restoring/Saving/Uploading settings
To restore/save/upload wireless router settings:
1. Click Administration on the navigation panel.
2. Click the
Restore/Save/Upload Setting tab.
4. Select a task from the configuration options:
• To restore to default factory settings, click
Restore, and click
OK once prompted.
• To save the current system settings, click
Save, navigate to
the folder where you intend to save the file and click Save.
• To restore from a saved system settings file, click
Browse to
locate your file, then click Upload.

Asus RT-N12 Series Specifications

General

Wireless Standard	IEEE 802.11b/g/n
Frequency Band	2.4 GHz
Data Rate	Up to 300 Mbps
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Operating Temperature	0 °C to 40 °C
Antenna	2 x external antennas
Encryption	64/128-bit WEP, WPA2-PSK, WPA-PSK
Security	Firewall
Firewall	SPI
Storage Temperature	-20°C to 70°C
Storage Humidity	20% to 90% RH
