Asus RT-N56U B1 User Manual

33
Using the FTP Share service
Sharing files via the FTP server
The ASUS Wireless Router enables you to share files from your
USB storage device via the FTP server with computers in LAN or
through the Internet.
IMPORTANT! To use this feature, you need to insert a USB
storage device, such as a USB hard disk or USB flash drive,
to the USB2.0 port on the rear panel of your wireless router.
Ensure that the USB storage device is formatted and partitioned
properly. Refer to the ASUS website at
http://www.asus com for the HD file system support table.
NOTE: Ensure that you safely remove the USB disk. Incorrect
removal of the USB disk may cause data corruption.
To share files via the FTP server:
1. Ensure that you have set up your FTP server through AiDisk.
2. Enable the DDNS service for FTP server access. To do this, follow
these steps:
a. From the navigation menu, click Advanced > WAN > DDNS
tab.
b. In the Enable the DDNS Client? field, tick Ye s.
c. Key in your User Name or E-mail Address and Password or
DDNS key.
d. Key in your Host name. The format should be
xxx.asuscomm.com, where xxx is your host name.
e. When done, click Apply.
3. From the navigation menu, click USB Application > Servers
Center > FTP Share tab and select the account that you want
to assign access rights to.

Asus RT-N56U B1 Specifications

General

Color	black
Frequency Band	2.4 ghz
Ethernet Standard	10/100/1000
Wireless Networking Standard	wi-fi 4
Wireless Standard	n
2.4 Ghz Streams	1
5.0 Ghz Streams	1
Gigabit Ethernet Speed	yes
Firewall	none
Ports	rj-45
WAN Ports	1
Built In Modem	yes

Weight and Dimensions

Height	6.8 inches
Width	5.7 inches
Net Weight	11.6 pounds
