Firmware Restoration
Firmware Restoration is used on an ASUS Wireless Router that
failed during its firmware upgrading process. It uploads the
firmware that you specify. The process takes about three to four
minutes.
To launch the rescue mode and use the Firmware Restoration
utility:
1. Unplug the wireless router from the power source.
2. Hold the Reset button at the rear panel and simultaneously
re-plugthewirelessrouterintothepowersource.Releasethe
Reset button when the Power LED at the front panel flashes
slowly, which indicates that the wireless router is in the rescue
mode.
3. UsethefollowingtosetupyourTCP/IPsettings:
IP address:192.168.1.x
Subnet mask: 255.255.255.0
4. From your computer’s desktop, click
Start > All Programs > ASUS Utility RT-N56U B1 Wireless
Router > Firmware Restoration.
IMPORTANT: Launch the rescue mode before using the
Firmware Restoration utility.

Asus RT-N56U B1 Specifications

General

Color	black
Frequency Band	2.4 ghz
Ethernet Standard	10/100/1000
Wireless Networking Standard	wi-fi 4
Wireless Standard	n
2.4 Ghz Streams	1
5.0 Ghz Streams	1
Gigabit Ethernet Speed	yes
Firewall	none
Ports	rj-45
WAN Ports	1
Built In Modem	yes

Weight and Dimensions

Height	6.8 inches
Width	5.7 inches
Net Weight	11.6 pounds
