EN 23
Removing and cleaning the wire guides
Only use conventional cleaners to clean the guides.
• Remove the screw using a screwdriver.
• Remove the guides from the holes in the back wall.
Make sure the spacers fitted on the wire guides are not lost.
Replace the spacers after cleaning; otherwise, sparks may appear.
Replacing the oven light bulb
The lamp in this household appliance is only suitable for
illumination of this appliance. The lamp is not suitable for
household room illumination.
Cut the power to the appliance by removing the plug from the
socket or switching off the fuse in the fuse box!
The bulb (halogen G9, 230 V, 25 W) is a consumable and therefore not
covered by warranty. Before changing the bulb, remove the trays, the
grid, and the guides.
• Remove the cover and the glass by removing the 4 screws.
• Replace the halogen light bulb.
NOTE: Use protection to avoid burns.
NOTE: There is a gasket on the cover which should not be removed.
Do not allow the gasket to be detached from the cover. The gasket
should fit correctly onto the oven cavity wall.
Re-tighten the cover screws firmly using a screwdriver; otherwise,
sparks may appear.
CLEANING

Atag CX4511C Specifications

General

Oven size	Medium
Oven type	Electric
Steam cooking	No
Number of ovens	1
Total oven power	3400 W
Number of shelves	1 shelves
Convection cooking	Yes
Keep warm function	-
Auto programs quantity	6
Defrost programs quantity	5
Number of shelf positions	4
Total oven(s) interior capacity	51 L
Maximum temperature (conventional)	250 °C
Control type	Rotary, Touch
Display type	LED
Door material	Glass
Product color	Black, Stainless steel
Control position	Top front
Appliance placement	Built-in
Number of glass door panels	3
Clock type	Electronic
Timer type	Digital
Energy consumption (conventional)	- kWh

Weight and Dimensions

Depth	547 mm
Width	597 mm
Height	458 mm
