OUTPUTS
Topic Description
General Displays a number of analogue and digital outputs
Fan Displays the activation of the fan
Element(s) Displays the activation of the element(s)
Converter(s) Displays the activation of the converter(s)
Oil circuit(s) Displays the activation of the oil circuit(s)
Main Motor Displays a number of digital outputs concerning the main motor status
SPM (Shock Pulse Method)
Topic Description
Motor, drive end Displays the vibration level at the drive end of the motor
Motor, non-drive end Displays the vibration level at the non-drive end of the motor
Low pressure stage,
drive end
Displays the vibration level at the drive end of the low pressure compressor
stage (when option is chosen)
Low pressure stage, non-
drive end
Displays the vibration level at the non-drive end of the low pressure compressor
stage (when option is chosen)
Gearbox Displays the vibration level at the gearbox
EVENT HISTORY
Topic Description
-
Displays a log file of all shutdowns and shows the status of the type, counters,
inputs and outputs at the moment a shutdown appeared
SETTINGS
Topic Description
Network Displays the CAN and ethernet configuration
Regulation Displays settings concerning the compressed air flow regulation
General Displays settings concerning time, date, unit and display time-out
Automatic Restart
Only displayed when compressor motor voltage < 690V and when ARAVF is
available. Automatic Restart After Voltage Failure can only be enabled by a
service technician.
Access Key Displays the controller access level that can be modified with password input
User Password
Displays the availability to use a password to protect the controller from
unwanted manipulation
Main Chart Displays the input and the range of the main chart
Remote control Displays the remote control mode (Password protected)
Main Motor Displays the settings of the main motor
Instruction book
APF221384 33
