9.3 Reference conditions and limitations
Reference conditions
Air inlet pressure (absolute) bar 1
Air inlet pressure (absolute) psi 14.5
Air inlet temperature ˚C 20
Air inlet temperature ˚F 68
Relative humidity % 0
Working pressure bar(e) See Compressor data
Working pressure psi See Compressor data
Limitations
Maximum working pressure bar(e) See Compressor data
Maximum working pressure psig See Compressor data
Minimum working pressure bar(e) 4
Minimum working pressure psig 58
Minimum ambient temperature ˚C 0
Minimum ambient temperature ˚F 32
9.4 Compressor data
G 15L
Compressor type 15k
W
100
psi
125
psi
150
psi
175
psi
7.5
bar
10
bar
13
bar
Frequency Hz 60 60 60 60 50 50 50
Maximum (unloading) pressure UL units bar 7.4 9.1 10.8 12.6 7.50 10 13
Maximum (unloading) pressure UL units psig 107 132 157 182 109 145 189
Nominal working pressure bar 6.9 8.6 10.3 12.1 7.0 9.5 12.5
Nominal working pressure psig 100 125 150 175 102 138 181
Set-point, thermostatic valve ˚C 60 60 60 60 60 60 60
Set-point, thermostatic valve ˚F 15.6 15.6 15.6 15.6 15.6 15.6 15.6
G 18
Compressor type 18k
W
100
psi
125
psi
150
psi
175
psi
7.5
bar
10
bar
13
bar
Frequency Hz 60 60 60 60 50 50 50
Maximum (unloading) pressure UL units bar 7.4 9.1 10.8 12.6 7.50 10 13
Maximum (unloading) pressure UL units psig 107 132 157 182 109 145 189
Nominal working pressure bar 6.9 8.6 10.3 12.1 7.0 9.5 12.5
Instruction book
80 2920 7119 21
