Temperature
Special Protection
Open
Closed
This chapter gives a general survey of available icons. Not all icons mentioned in this
chapter are applicable to every machine.
4.4 Main screen
Function
The Main screen is the screen that is shown automatically when the voltage is switched on. It is
switched off automatically after a few minutes when there is no touch input.
Description
Reference Designation Function
1 Home button The home button is always shown and can
be tapped to return to the main screen.
2 Screen information On the main screen, the screen information
bar shows the serial number of the machine.
When scrolling through menus, the name of
the current menu is shown.
3 Access level button The access level button is always shown and
can be tapped to change the current user
access level.
Instruction book
50 2920 7118 31
