Reference Description
F1/2/3/4 Fuses
KL Line contactor
PE Earth terminal
El Elektronikon controller
S3 Emergency stop button
K2 Fan motor contactor
Q2 Fan motor circuit breaker
U1 Frequency converter
X12 CAN bus connector
SSA/SSB Service switch
External box
Reference Description
F6 Fuses
PE Earth terminal
Q1 Main switch
S1 Local / LAN switch
P3 Ammeter
2.8 Electrical diagram
The complete electrical diagram can be found in the electric cubicle.
Instruction book
16 2920 7104 10
