Fuse specifications IEC: gL/gG
Fuse specifications CSA: HRC Form II - UL: Class 5
11.3 Settings of fan motor circuit breaker
Circuit breaker
GA 75 VSD GA 90 VSD
Frequency (Hz) Voltage (V) Fan motor circuit
breaker Q15 (A)
Fan motor circuit
breaker Q15 (A)
IEC
50 400 5 7.7
50 500 4.2 6.2
60 380 5 8.0
CSA/UL
60 460 5 7.3
60 575 4.1 5.8
11.4 Reference conditions and limitations
Reference conditions
Air inlet pressure (absolute) bar 1
Air inlet pressure (absolute) psi 14.5
Air inlet temperature ˚C 20
Air inlet temperature ˚F 68
Relative humidity % 0
Working pressure for GA 75 and GA 90 VSD See section Compressor data
On water-cooled units also:
Cooling water inlet temperature ˚C 20
Cooling water inlet temperature ˚F 68
Limitations
Maximum working pressure for GA 75 up to GA 90 VSD See section Compressor data
Minimum working pressure bar(e) 4
Minimum working pressure psig 58
Maximum air inlet temperature ˚C 40
Maximum air inlet temperature ˚F 104
Minimum air inlet temperature ˚C 0
Minimum air inlet temperature ˚F 32
Maximum altitude operation m 1000 m above sea level
Instruction book
2920 1634 04 103

Atlas Copco GA 75 VSD Specifications

General

Brand	Atlas Copco
Model	GA 75 VSD
Category	Air Compressor
Language	English
