COMPRESSOR/ENGINE/GENERATOR SPECIFICATIONS
REFERENCE CONDITIONS
The inlet conditions are specified at the air inlet grating outside the canopy.
LIMITATIONS
Designation
XAHS 146 Dd
XAHS 300 DD6
XATS 156 Dd
XATS 350 DD6
XA(S) 186 Dd
XA(S) 375 DD6
XAVS 166 Dd
XAVS 340 DD6
XAHS 186 Dd
XAHS 375 DD6
XATS 156 Dd
XATS 350 DD6
XA(S) 186 Dd
XA(S) 375 DD6
COM3 COM3 COM3 COM3 COM3 COM2 COM2
Absolute inlet pressure bar 1 1 1 1 1 1 1
psi 14.5 14.5 14.5 14.5 14.5 14.5 14.5
Relative air humidity % 0 0 0 0 0 0 0
Air inlet temperature °C 20 20 20 20 20 20 20
°F 68 68 68 68 68 68 68
Nominal effective working pressure bar 12 10.5 7 14 12 10.3 7
psi 174 152 102 203 174 149 102
Designation
XAHS 146 Dd
XAHS 300 DD6
XATS 156 Dd
XATS 350 DD6
XA(S) 186 Dd
XA(S) 375 DD6
XAVS 166 Dd
XAVS 340 DD6
XAHS 186 Dd
XAHS 375 DD6
XATS 156 Dd
XATS 350 DD6
XA(S) 186 Dd
XA(S) 375 DD6
COM3 COM3 COM3 COM3 COM3 COM2 COM2
Minimum effective receiver pressure bar 4 4 4 4 4 4 4
psi 58585858585858
Maximum effective receiver pressure,
compressor unloaded
bar 13.5 11.8 8.5 15.5 13.5 11.8 8.5
psi 196 171 123 225 196 171 123
Maximum ambient
temperature at sealevel
no
aftercooler
°C 50 50 50 45 45 50 50
°F 122 122 122 113 113 122 122
with
aftercooler
°C 49 47 47 40 40 - -
°F 114 114 114 104 104 - -
Minimum starting
temperature
no
aftercooler
°C -10 -10 -10 -10 -10 -10 -10
°F 14 14 14 14 14 14 14
with
aftercooler
°C -20 -20 -20 -20 -20 -20 -20
°F -4 -4 -4 -4 -4 -4 -4
