Atlas Copco XAHS 186 Dd User Manual

- 67 -
PERFORMANCE DATA
At reference conditions, if applicable, and at normal shaft speed, unless otherwise stated.
1)
Free Air Delivery (volume flow rate) is measured according to ISO 1217 ed.3 1996 annex D
Tolerance:
• +/- 5% 25 l/s (53 cfm) < FAD < 250 l/s (530 cfm)
• +/- 4% 250 l/s (530 cfm) < FAD
The international standard ISO 1217 corresponds to following national standards:
• British BSI 1571 part 1
• German DIN 1945 Part 1
• Swedish SS-ISO 1217
• American ANSI PTC9
Designation
XAHS 146 Dd
XAHS 300 DD6
XATS 156 Dd
XATS 350 DD6
XA(S) 186 Dd
XA(S) 375 DD6
XAVS 166 Dd
XAVS 340 DD6
XAHS 186 Dd
XAHS 375 DD6
XATS 156 Dd
XATS 350 DD6
XA(S) 186 Dd
XA(S) 375 DD6
COM3 COM3 COM3 COM3 COM3 COM2 COM2
Engine shaft speed, normal and maximum r/min 2300 2300 2300 2200 2200 2300 2300
Engine shaft speed, compressor unloaded r/min 1700 1700 1700 1700 1700 1700 1700
Free air delivery
1)
standard l/s 151 161 185 158 173 166 185
cfm 320 341 392 335 367 352 392
with
aftercooler
l/s 147 157 181 154 169 - -
cfm 311 333 384 326 358 - -
DD6.book Page 67 Monday, November 10, 2014 11:25 AM
