CHAPTER3 Physical Description
Mediant 800 Gateway & E-SBC | Hardware Installation Manual
Table 3-8: STATUS LED Description
LED
Color
LED State Description
Green On The device is operational and in Standalone mode (not in High-
Availability mode).
Fast
Flashing
■ Initial rebooting stage.
■ Software upgrade (.cmp file) in process (supported only from
Software Version 7.2).
Slow Flash HA mode - LED on Active device.
Slow-Fast
Flash
HA mode - LED on Redundant device.
Red On Boot failure.
Off Advanced rebooting stage.
Power LEDs
The power LEDs depend on the Mediant 800 model.
Power LED
The POWER LED indicates the power supply status, as described in the following table.
Table 3-9: POWER LED Description
LED Color LED State Description
Green On Power is received by the device.
- Off No power received by the device.
The POWER LED is applicable only to Mediant 800B.
AC PWR LED
The AC PWR LED indicates the AC power supply status, as described in the following table.
Table 3-10: AC PWR LED Description
Color State Description
Green On AC power is received by the device.
- Off No power received by the device.
The AC PWR LED is applicable only to Mediant 800C.
