AudioCodes Mediant 800 Series User Manual

CHAPTER5 Cabling the Device
Mediant 800 Gateway & E-SBC | Hardware Installation Manual
■ Mediant 800C: AC and DC redundant power. When both power supplies are used (AC and
DC), the device is powered from the AC power source only. The DC source starts feeding the
device only upon an AC power outage.
For Mediant 800C, the device is always shipped with AC power support. DC power is
also available if the device is ordered with DC support (AC/DC power adaptor is
provided).
Connecting to AC Power
The device receives power from a standard alternating current (AC) electrical outlet. The
connection is made through the supplied AC power cord.
Table 5-4: AC Power Specifications
Physical
Specification
Value
Input Voltage Single universal AC power supply 100 to 240V
AC Input Frequency 50 to 60 Hz
AC Input Current ■ Mediant 800B: 4 A (max.)
■ Mediant 800C: 1.5 A (max.)
Max. Power
Consumption
■ SBC Only (no PSTN): 27W
■ Gateway (without OSN): 60W*
* Power consumption varies according to the assembled hardware
configuration.
● The device must be connected to a socket-outlet providing a protective earthing
connection.
● To avoid electric shock or fire, use only the AC power cord that is supplied by
AudioCodes with the device.
● For replacing the power fuse, see Replacing the Power Fuse on page32.
ご注 意
本 製 品 に添 付 の電 源 ケーブルは、Mediant 800 Gateway & E-SBC に専 用 設 計 されて
いるため、汎用性がありません. 本 電 源 ケーブルを他 の機 器 に使 用 されないよう、ご注意
ください.
➢ To connect the device to AC power:
1. Connect the plug of the AC power cord (supplied) to the device's AC power socket (labeled
100-240V ~ 4A 50-60Hz), located on the rear panel.
- 28 -
