AudioCodes Mediant 800 Series User Manual

CHAPTER1 Introduction
Mediant 800 Gateway & E-SBC | Hardware Installation Manual
1 Introduction
This document provides a hardware description of the Mediant 800 Gateway and E-SBC (hereafter
referred to as device) and step-by-step procedures for mounting and cabling the device.
The device supports the following interfaces (customer ordered):
■ E1/T1 (PRI):
● Mediant 800B: Up to 2 E1/T1 port interfaces (over single copper wire pair).
● Mediant 800C: Up to 4 E1/T1 port interfaces
■ Up to 8 BRI ports (supporting up to 16 voice channels).
■ Up to 12 FXS port interfaces.
■ Up to 12 FXO port interfaces.
■ 12 LAN Ethernet interfaces - up to 4 Gigabit Ethernet ports and up to 8 Fast Ethernet ports.
These ports operate in port-pair redundancy, providing up to 6 port-pair groups.
■ Open Solutions Network (OSN) server platform for hosting third-party applications such as an
IP PBX.
■ Power:
● Mediant 800B: Single AC power inlet
● Mediant 800C: Single AC power inlet, and a DC power inlet (optional, customer ordered)
● Mediant 800 includes two hardware revisions which differ as follows:
✔ Mediant 800B: Max. 2 E1/T1; AC power only
✔ Mediant 800C: Max. 4 E1/T1; AC and DC power (optional)
● Hardware configurations may change without notice. Currently available hardware
configurations are listed in AudioCodes Price Book. For available hardware
configurations, contact your AudioCodes sales representative.
● The Fast Ethernet ports are available only on "pure" SBC Mediant 800 (i.e., without
PSTN / Gateway interfaces).
● For software configuration, refer to the User's Manual.
- 1 -

AudioCodes Mediant 800 Series Specifications

General

Brand	AudioCodes
Model	Mediant 800 Series
Category	Gateway
Language	English
