DC inverter ARV Individual Series technical manual
82
TNX: Total capacity index
ARVLD-H028/4R1A:74.07×2.2/84.1＝1.94kW
ARVMD-H100/4R1A:74.07×10.0/84.1＝8.81kW
ARVMD-H056/4R1A:74.07×5.6/84.1＝4.93kW
3.7 Control discipline
3.7.1 Explanation of symbols
HPS
high pressure switch
Pd sensor
high pressure sensor
Ps sensor
low pressure sensor
Tao
outdoor ambient temperature
Tdi
discharge temperature of inverter compressor
Tda/b
discharge temperature of fix speed compressor
Ts
total suction temperature
Tdef
defrost temperature
Tci
total gas collecting tube temperature
SV0
4 way valve
SV1、SV2
unload valve
SVC
Liquid bypass electromagnetic valve
PMV1
EXV1
PMV2
EXV2
PMV3
EXV3
3.7.2 Start up control discipline
 Starting up of outdoor unit
Cooling mode
(1)The compressor operate at 45Hz or 53Hz for 3 minutes, then go to the automatic adjustment.
(2)Solenoid valve SV1 opens for 20 seconds.
(3)Outdoor and indoor units adjust automatically.
Heating mode
(1) The compressor operate at 45Hz or 53Hz for 3 minutes, then go to the automatic adjustment.
(2) Solenoid valve SV1 opens for 20 seconds.
(3) Outdoor and indoor units adjust automatically.
 Startup of compressor
