Avaya Ethernet Routing Switch 3600 Series User Manual

Label Color/Status Description
Solid Amber SFP detected and Link
established.
Amber / blinking SFP link established and
transmit activity detected.
Green / slow blinking RX & TX blinking together in a
slow pattern indicate that the
port has been disabled by the
software.
Rx Off No link established.
Solid Green SFP+ detected and link
established.
Green / blinking SFP+ link established and
receive activity detected.
Solid Amber SFP detected and link
established.
Amber / blinking SFP link established and
receive activity detected.
Green / slow blinking RX & TX blinking together in a
slow pattern indicate that the
port has been disabled by the
software.
IP address information configuration
The following sections contain information necessary to configure IP address parameters on the
switch.
Connecting a console
Before you begin
• Terminal with AC power cord and keyboard
• Serial cable — a DB-9 to RJ-45 adapter or other suitable console cables can be used – the
maximum length of a console cable is 25 feet (8.3 meters)
Procedure
1. Connect one end of serial cable to the DB—9 connector on the terminal.
2. Connect the other end of the serial cable to the RJ–45 connector on the switch.
3. Turn the terminal on.
Installing ERS 3600 in an equipment rack
January 2017 Installing Avaya Ethernet Routing Switch 3600 Series 32
Comments on this document? infodev@avaya.com
