Axon Fleet Installation Manual

7
One Bluetooth Dongle – SKU 74027
This dongle is plugged in to a USB port on the vehicle's mobile data terminal (MDT), the
in-vehicle Windows laptop computer. The dongle is provided by Axon and enables the
MDT to have Bluetooth low-energy (BLE) capabilities. This is required for the MDT to
communicate with the Axon Fleet cameras
Wiring Harness Assemblies
Two power unit to mount cables
These cables are 18 feet (5.5 m) in length and contain the following wires
• 18 AWG – White
• 18 AWG – Gray
• 24 AWG – Green
• 24 AWG – Violet
Two power unit to vehicle cables
These cables are 10 feet (3 m) in length and contain the following wires
• 18 AWG – Orange – 2 amp fuse
• 18 AWG – Black
• 18 AWG – Red – 2 amp fuse
