7. Important information
Active screen size (H x V) 267,3 mm x 475,2 mm (10.52” x 18.71”)
Aspect ratio (H:V)
16:9
Resolution
2MP (1920 x 1080)
Pixel pitch 0.2475
Color imaging
Yes
Gray imaging
Yes
Color support
10 bit; 16,7 million colors
Viewing angle (H, V) 178°
Ambient Light Compensation
(ALC)
Yes, preset values in OSD
Front sensor Yes
Maximum luminance 250 cd/m² typical
DICOM calibrated luminance 180 cd/m²
Contrast ratio
1000:1 typical
Responsetime(Tr+Tf)
14 ms
Housing color
Black + Silver
Video input signals
VGA, DisplayPort, HDMI
USB ports
1 upstream, 2 downstream
USB standard 2.0
Power requirements (nominal)
100-240 V
Power consumption (nominal) 40 W (<0,5 W in stand-by)
Power save mode Yes
Power management
DPMS
Dot clock 165 MHz
OSD languages English, French, German, Spanish, Italian, Dutch, Japanese, T raditional
Chinese, Simplified Chinese, Korean
Dimens ions with stand (W x H
xD)
507 x 377–457x 166 mm
Dimensions w/o stand (W x H
xD)
507 x 306 x 57 mm
Dimensions packaged (W x H
xD)
610 x 505 x 230 mm
Net weight with stand 6.0 kg
Net weight w/o stand
3.6 kg
Net weight packaged with
stand
9.6 kg
Height adjustment range 80 mm
Tilt
0° / +20°
Swivel -30° / +30°
Pivot
N/A
Mounting standard
VESA (75 m m)
Screen protection N/A
Certifications CE (MDD 93/42/EEC class I product), CE - 2004/ 108/EC, IEC
60950-1:2005 + A1:2009 (2ND EDITION), IEC 60601-1 2ND ED:1988
+ A1:1991 + A2:1995, UL 60601-1 1ST EDITION, CAN/CSA-C22.2
NO. 601.1-M90:2005, IEC 60601-1:2005 + A1:2012, ANSI/AAMI
ES 60601-1:2005 + C1:2009 + A1:2012, CAN/CSAC22.2 No.
60601-1-08:2008, DEMKO - EN 60601- 1:2006, EN 60601-1-2:2007,
CCC - GB9254-2008 + GB4943-2001 + GB17625.1-2003, KC, VCCI,
FCC class B, ICES-001 Level B, FDA Class I device, RoHS
34 K5903049 EONIS 19/02/2014
