Baumuller b maxx BM4400 User Manual

Supported operation modes of the CANopen device profile DSP402
Application Manual POWERLINK Controlled Node
Document no. 5.13013.04 Baumüller Nürnberg GmbH
14
of 80
3.3
3.3.2 Operating modes and field bus objects
Operating modes
Device Control
All prescribed and all optional objects are supported.
Field bus object
number
mandatory/
optional
Field bus object name
0x6040 mandatory controlword
0x6041 mandatory statusword
0x605A optional quick_stop_option_code
0x605B optional shutdown_option_code
0x605C optional disable_operation_option_code
0x605D optional stop_option_code
0x605E optional fault_reaction_option_code
0x6060 mandatory modes_of_operation
0x6061 mandatory modes_of_operation_display
Homing Mode
All prescribed and all optional objects are supported.
Field bus object
number
mandatory/
optional
Field bus object name
0x607C optional home_offset
0x6098 mandatory homing_method
0x6099 SIX 0 = 2 mandatory homing_speed
0x609A optional homing_acceleration
Profile Position
Mode
(Positioning)
All prescribed and partly all optional objects are supported.
Field bus object
number
mandatory/
optional
Field bus object name
0x607A mandatory target_position
0x607D SIX 0 = 2 optional software_position_limit
0x607F optional max_profile_velocity
0x6080 optional max_motor_speed
0x6081 mandatory profile_velocitiy
0x6083 mandatory profile_acceleration
