38
HANDLE ASSY EXPLODED VIEW
A5CO4400
A5RICZ010
Screws are
A5SCSQ001
(8 per assembly)
AAME4415
WARR9824
WARR9824
A5ME4414-BLK
A5BRZN010
A5HKSY020
A5NUNY070
A5WAFL050
WACA8003
WACA8003
A5SCHX016
A5WAFL050
A5WAFL030
A5BOPH220
A5SP1801
A5SENY071
A5PICV030
A5SENY170
A5NUNY050
A5NUNY050
A5BOCG090
A5NULO050
