Bay-Tek Willy Crash User Manual

39
PART # DESCRIPTION
PART # DESCRIPTION
PARTS LIST
A5BK1013 Bracket, Pushbutton/Counters
A5BK6035 Bracket, Light
A5BK9999 Bracket, Power Supply Mounting
A5BTRT010 #4 Nylon Push Pins
A5BURU075 Bumper,Rubber,2 1/4x2 5/8,Black
A5CB1499 Coin Box, White
A5CO4203 Cover, Speaker
A5CO4400 Cover Grip, Slide On, Handle
A5FI9010 Filter, F1700ca06, Inline
A5HO1003 Holder, For Light Bars
A5LI0003 Light,A19,9 Watt,60w
A5LK2001 Lock, Cash Box, A05/E00 Key Code
A5LK5002 Lock, 7/8", H95 Key Code
A5ME2035 Ticket Tray, Metal
A5ME4182 Metal, Cashbox Guide
A5ME4414-BLK Metal, Handle Guide Assy
AAME4415 Metal, T-Handle, w/ grips & bumpers
A5ME5508 Metal, Bracket, Graphics Card
A5PICV032 Pin,Clevis,1.4"D X 1-5/8"L
A5PL4200 Plate, Up Stacker
A5PL8900 Plate, Blanking, Bill Validator
A5RICZ010 Ring,Cotter,7/16"-1/2" Shaft
AASW200 Low Ticket Switch
A5VF8000 Vacuum Form, Monitor Cover
A5DE0042 Decal, Menu/Vol
A5DE8010 Decal, Marquee Back
A5DE8011 Decal, Cannon Wrap
A5DE8012 Decal, Floor Cover, Right
A5DE8013 Decal, Floor Cover, Left
A5DE8014 Decal, Marquee Front
A5DE8015 Decal, Marquee Cover
A5DE8016 Decal, Control Panel
A5DE8017 Decal, Control Panel Star
A5DE8018 Decal, Outer Door
A5DE8019 Decal, Inner Door
A5DE8020 Decal, Monitor Pillar
A5DE8021 Decal, Left Cabinet Side
A5DE8022 Decal, Right Cabinet Side
W5HG1025
Hinge,16",Double Bend
W5HG1065
Hinge,5-75,Single Bend
W5KE5000
Keeper, Lock
W5TM4002
T-Molding,7/8"Blue
A5CORD1 Cord,Power,10' Works W/Outlet Strip
A5CORD55 Cord, 10' HDMI To HDMI
A5CORD5 Cord, AC Computer Cord, 6.5'
A5CORD58 Cable, USB, Male A To Micro, 3ft
A5SP4100 Splitter, Detach Power Supply Cord Y
AACE8000 Cable Assy, Addressable Light Power
AACE8001 Cable Assy, Speaker Power
AACE8002 Cable Assy, Plunger Sensor
AACE8003 Cable Assy, 5V Addressable Light Power
AACE8004 Cable Assy, Dba
AACE8005 Cable Assy, Menu/Select/Counters
AACE8006 Cable Assy, Coin Door/Ticket Dispenser
AACE8007 Cable Assy, Cannon Led Power
AACE8008 Cable Assy, Monitor Lights Power
AACE8009 Cable Assy, Left Bottom Side RGB
AACE8010 Cable Assy, Bottom Sides RGB Light
AACE8011 Cable Assy, Monitor RGB Blue Light
AACE8012 Cable Assy, Star Light Power
AACE8013 Cable Assy, Control Panel Light Power
AACE8014 Cable Assy, Door Board To Power Distribution
AACE8015 Cable Assy, Audio Board Power
AACE8017 Cable Assy, Power To Service Light
AACE8018 Cable Assy, Power To Marquee Lights
AACE8019 Cable Assy, Line Filter
AACE8020 Cable Assy, Ground, T-Handle To Ground Stud
AACE8021 Cable Assy, Ground, Coin Door To Hinge
AACE8022 Cable Assy, Ground, Ticket Dispenser To Hinge
AACE8023 Cable Assy, Ground, Hinge To Ground Stud
AACE8024 Cable Assy, Ground, Power Supply To Stud
AACE8025 Cable Assy, Servicing Stick Light
AACE8026 Cable Assy, RGB Cannon Stick Lights
AACE8027 Cable Assy, Cannon RGB Stick Light
AACE8028 Cable Assy, Bottom Right Side Jumper
AACE8029 Cable Assy, Front Floor LED lights
AACE8811 Cable Assy, Speaker
AACE8868 Cable Assy, Fluorescent
A5PS1013 Power Supply, EVGA 500
A5GC8000 Graphics Card
AAMO5503-WC Monitor, 55" TV
A5TD1 Ticket Dispenser, Entropy
A5CB9600 PCB, Audio Amplifier
AACB9604 Board, Door Interface
AACB5156 PCBA, Power Dist.
AACB8001 PCBA, Light Driver Board
AACB3850A Board, Launch Sensor
AAMB10-HD Mother Board, W/Hard Drive
AACO1020 Counter Assy, No Feet
AAPB2700 Push Button Assembly
A5CE2300 Cable, Audio Isolator
A5CEAU010 Cable, Audio Stereo,3.5mm , M-M 2ft
