Controls
Labelling Function Function:
Brief actuation
Function:
Actuation > 5 sec.
OPEN OPEN command
STOP If drive is in motion: STOP
If drive is at a halt: Light on/
off if light function with
stopping time is set
Confirmation of a fault,
storage of a limit position
CLOSE CLOSE command
It is not possible to move the door while the "STOP" button
is actuated or a safety device in the emergency stop cir-
cuit has triggered.
Checking the running direction
Open the cover of the door control unit by undoing the four cover screws and re-attach
the cover offset upwardly.
The direction of drive rotation depends on how the three mains phases are connected
to the control unit and has to be checked first. Proceed as follows:
• Move the door into the semi-opened position using the emergency manual opera-
tion function.
• Insert the CEE plug into the CEE socket or turn on the main switch.
• Check that the control unit is in the setting mode.
• Using the UP and CLOSE buttons, check whether the direction of movement of the
door corresponds to the buttons pressed.
If the direction of movement does not correspond to the button commands, proceed as
follows:
• Disconnect the control unit safely from the mains.
• Change over two phases at the mains connection terminals, e.g., the cables at ter-
minals L1 and L3 (refer to the "Complete connecting diagram").
• Check the direction of movement again.
10
