Setting the DIP switches
Switch Position Function
DIP 1
ON Electric or pneumatic safety edge is connected
OFF Optoelectronic safety edge OSE is connected
DIP 2
ON Pneumatic safety edge (DW) connected, pressure wave test-
ing is active
OFF Electric safety edge is connected
DIP 3
ON Terminating resistance of the safety edge = 8.2 kΩ
OFF Terminating resistance of the safety edge = 1.2 kΩ
DIP 4
ON Downward travel in maintained operation mode (only with
safety edge)
OFF Closing in dead-man mode
DIP 5
ON Reverse travel after time in presence of obstacle
OFF UP limit position in presence of obstacle
DIP 6
ON Automatic closing OFF
OFF Automatic closing 60 seconds ON
DIP 7
ON Switch off in CLOSED limit position via safety edge
OFF Switch off in CLOSED limit position via limit switch
DIP 8
ON Relay function door position limit position OPEN
OFF Relay function testing
Status indications
The status display shows the current status of the control unit. It can be found above
the OPEN button.
Description
Control unit ready for operation
Automatic closing activated
Safety input SE activated
Safety input SE negative testing, pre-
limit switch set too high
18
