General
This door control unit is a high-quality product with the following performance charac-
teristics:
• Evaluation of safety sensors on the door (e.g. closing edge surveillance, pull-in
safety device and similar)
• Evaluation of additional safety devices on the door (e.g. light barriers, light grids
and similar)
• Evaluation of control sensors on the door (e.g., pull switch, induction loop and sim-
ilar)
• Evaluation of EMERGENCY STOP control sensors
• Supplying sensors and control sensors with 12 V safety extra-low voltage
• Operation of application-specific outputs
Please observe these Assembly and Operating Instructions when installing and setting
up the equipment.
Explanation of pictograms
CAUTION
CAUTION indicates a hazardous situation
which, if not avoided, could result in injury.
ATTENTION
ATTENTION indicates measures that must be
taken to avoid damage to property.
Denotes user tips and other useful information.
Warranty
Structural modifications and incorrect installation which are not in accordance with
these and our other instructions can result in serious injuries, e.g., crushing of limbs.
Therefore, structural modifications may only be carried out with our prior approval and
strictly in accordance with our instructions, particularly the information contained in
these Assembly and Operating Instructions.
Any further processing of the products which does not comply with their intended use is
not permitted.
The end product manufacturer and fitter have to ensure that all the relevant current
statutory, official and, in particular, EMC regulations are adhered to during utilisation of
our products, especially with regard to end product manufacture, installation and cus-
tomer advice.
