Programming
BC8050 und BC815058 Version: 3.0.0
Seriell_Set data structure
The settings for the RS232 interfaces are transferred with the following data structure.
TYPEST_COMConfig:
STRUCT
iInputData:INT;(*BC8150:1..255*)
iOutputData:INT;(*BC8150:1..255*)
Modbus_Mode_BC8150:E_BC8150_Mode;(*_8data_no_parity,_8data_with_parity,_8data_even_par-
ity,_8data_odd_parity*)
iWatchdog:INT;(*1000msWatchdogfürdieModbusundKS8000Kommunika-
tion,0msWatchdogdisabled*)
Modbus_Baudrate:ENUM;(*_1k2Baud,_2k4Baud,_4k8Baud,_9k6kBaud,_19k2Baud,_38k4Baud*)
END_STRUCT
END_TYPE
Key
iInputData: Number of input data (from the point of view of the BC). Size in words for the KS8000 protocol
(address 1-39)
iOutputData: Number of output data (from the point of view of the BX). Size in words for the KS8000
protocol (address 1-39)
Modbus_Mode_BC8150: RS232 settings for the ModbusRTU protocol (address 40-59)
iWatchdog: Watchdog for KS8000 and Modbus protocol
Modbus_Baudrate: Baud rate for the ModbusRTU protocol (address 40-59)
iErrorId
Return parameter iErrorId Meaning
0 no Error
-1 Wrong BC Typ
-2 Wrong firmware version
0x1000_xxxx xxxx ADS Error Code (see ADS Return Code)
5.12.3 TcBaseBCxx50
5.12.3.1 System task information
VAR_GLOBAL
SystemTaskInfo:SYSTEMTASKINFOTYPE;
END_VAR
System flags are implicitly declared variables. Using the Input Assistant, a variable SystemTaskInfoArr can
be found under system variables. This variable is a field with four structures of type SYTEMTASKINFOTYPE
[}58]. The structure definition can be found in the system library. The index in this field is the task ID.
Development environment Target platform PLC libraries to be linked
TwinCAT v2.9.0 BCxx50, BC9x20 Controller TcBaseBCxx50.lbx
5.12.3.2 System Task Info Type
TYPESYSTEMTASKINFOTYPE
STRUCT
active:BOOL;
taskName:STRING(16);
firstCycle:BOOL;
cycleTimeExceeded:BOOL;
cycleTime:UDINT;
lastExecTime:UDINT;
priority:BYTE;
cycleCount:UDINT;
END_STRUCT
END_TYPE
