Beckhoff CX5140 User Manual

Seconds UPS
3.4 Data Types
3.4.1 TYPE E_S_UPS_Mode
eSUPS_WrPersistData_Shutdown: write persistent data and then QuickShutdown
eSUPS_WrPersistData_NoShutdown: write persistent data only (no QuickShutdown)
eSUPS_ImmediateShutdown: QuickShutdown only (no writing of persistent data)
eSUPS_CheckPowerStatus: determine status only (neither write persistent data nor QuickShutdown)
Prerequisites
Development environment Target plat-
form
Hardware PLC libraries to include
TwinCAT v2.11R3 Build 2047 or higher
TwinCAT v3.1 Build 4018 or higher
PC (i386) Seconds UPS TcSUPS_CX51x0.Lib
3.4.2 TYPE E_S_UPS_State
eSUPS_PowerOK:
in all modes: supply voltage is OK
eSUPS_PowerFailure:
in all modes: Supply voltage faulty (applied for one cycle only)
eSUPS_WritePersistentData:
in eSUPS_WrPersistData_Shutdown mode: writing of the persistent data is active
in eSUPS_WrPersistData_NoShutdown mode: writing of the persistent data is active
eSUPS_QuickShutdown:
in eSUPS_WrPersistData_Shutdown mode: QuickShutdown is active
in eSUPS_ImmediateShutdown mode: QuickShutdown is active
eSUPS_WaitForRecover:
in eSUPS_WrPersistData_NoShutdown mode: wait for return of the voltage
in eSUPS_CheckPowerStatus mode: wait for return of the voltage
eSUPS_WaitForPowerOFF:
in eSUPS_WrPersistData_Shutdown mode: wait for shutdown by the UPS
in eSUPS_ImmediateShutdown mode: wait for shutdown by the UPS
Prerequisites
Development environment Target plat-
form
Hardware PLC libraries to include
TwinCAT v2.11R3 Build 2047 or higher
TwinCAT v3.1 Build 4018 or higher
PC (i386) Seconds UPS TcSUPS_CX51x0.Lib
CX51x0 29Version: 1.6

Beckhoff CX5140 Specifications

General

CPU Cores	4
USB Ports	2 x USB 2.0
Power Supply	24 V DC
Protection Class	IP20
Real-Time Ethernet	EtherCAT
Operating System	Windows Embedded Standard 7
Ethernet Ports	2
Operating Temperature	-25 °C to +60 °C

Summary

Foreword

Safety instructions

Essential guidelines for safe operation and installation.

Product overview

Intended use

System overview

Seconds UPS

S-UPS: capacitive one-second UPS

Explains the integrated power backup system for data protection.

Overview

Details the functionality and integration of the Seconds UPS with PLC programs.

Functions

Mounting and wiring

Unpacking, installation and transport

Covers procedures for receiving, handling, and installing the device.

Installation on the mounting rail

Step-by-step guide for mounting the device on a DIN rail.

Power supply

Explains the requirements and connection methods for the device's power supply.

Installation of passive terminals at the CX51x0 power supply unit

Commissioning/Configuration

BIOS setup

Instructions on accessing and configuring the system's BIOS settings.

Advanced

Chipset

Security

Boot

EtherCAT cable redundancy

Explains how to configure network redundancy for EtherCAT.

Operating CX51x0-N03x with TwinCAT

Guide for integrating and operating the device with TwinCAT software.

Switching on and off

Procedures for powering the system on and off correctly.

Error handling and diagnostics

Basic CPU module

Describes the status LEDs on the main CPU module for diagnostics.

Faults

Provides a guide to common faults and their potential solutions.
