Commissioning/Configuration
5.1.3 Chipset
Aptio Setup Utility - Copyright (C) American Megatrends, Inc.
►North Bridge
►South Bridge
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Options
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Quit
Version 2.17.1246. Copyright (C) 2014 American Megatrends, Inc.
North Bridge
Settings for internal graphics parameters (memory/ render units / behavior)
These settings are critical for the real-time behavior of the system! The settings are optimized ex factory
and should therefore only be changed if one knows exactly
how the parameter influences the behavior.
South Bridge
Setting for sound interface, USB configuration / PCI Express configuration.
5.1.3.1 South Bridge
Aptio Setup Utility - Copyright (C) American Megatrends, Inc.
► Azalia HD Audio Disabled for Windows XP
► USB Configuration
► PCI Express Configuration
High Precision Time [Enabled]
Restore AC Power Loss [Power On]
Onboard Device Configuration
Onboard Gigabit LAN 1 [Enabled]
Onboard Gigabit LAN 2 [Enabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Options
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Quit
Version 2.17.1246. Copyright (C) 2014 American Megatrends, Inc.
Attention
The USB configuration settings should not be changed!
Changes to the USB controller settings can make the system inoperable by inadvertently
disabling local inputs.
CX51x0 67Version: 1.6
