Secure 4/8 port KM Switch User Manual
SECTIONS
Table of Contents
1 3 4 5 6 7
OVERVIEW
2
Product Specifications
Part No. F1DN104K-3 (4-port version)
F1DN108K-3 (8-port version)
Enclosure Metal enclosure with high-impact aluminum
faceplate
Power Requirements (F1DN104K-3) 12V DC, 1.5A (maximum)
power adapter with center-pin-positive
polarity
(F1DN108K-3) 100 –240VAC, 0.9A
Freq. 50/60Hz
AC Input Voltage 100 to 240VAC
No. of Users Supported 1
No. of Computers Supported (F1DN104K-3) 4
(F1DN108K-3) 8
Console Keyboard Input (F1DN104K-3) USB Type A +
PS/2 Mini-DIN 6-pin female connector
(F1DN108K-3) USB Type A connector
Console Mouse Input (F1DN104K-3) USB Type A +
PS/2 Mini-DIN 6-pin female connector
(F1DN108K-3) USB Type A
Console Headset /
Speaker output jack
1/8" (3.5mm) female
Computer Keyboard/Mouse Ports USB Type B
Computer Audio Input Jack 1/8" (3.5mm) female
Port Selector push-buttons (F1DN104K-3) 4
(F1DN108K-3) 8
Channel Selected LED Indicators (F1DN104K-3) 4
(F1DN108K-3) 8
User Channel Selection Methods Front panel push-buttons, SCS
Settings Display physical size, display resolution X /
Y, display orientation (portrait /landscape),
display head (1st, 2nd,16th), display location
(coordinates), mouse speed (1-10), mouse
acceleration (1-10), SCS enable / disable,
prevent transition while dragging – enable
/ disable.
Operating Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
MTBF 14 years (per MIL-HDBK-217E)
Warranty 3 years
Dimensions (F1DN104K-3) 12.5 (W) x 6.4 (D) x 1.7 (H) inch
/ 317.5 (W) X 162.56 (D) X 43.18 (H) mm
(F1DN108K-3) 17.25 (W) x 7.95 (D) x 1.7 (H)
inch / 438.15 (W) X 201.93 (D) X 43.18 (H) mm
Weight (F1DN104K-3) 4 lbs. / 1.81 KG
(F1DN108K-3) 9 lbs / 4.08KG

Belkin F1DN104K-3 Specifications

General

Console ports	3.5mm headphone, USB A
Audio connections	Yes
Headphone outputs	1
USB connector type	USB Type-A
Number of computers controlled	4
Built-in display	No
Power source	AC
Input current	1.5 A
AC input frequency	50 - 60 Hz
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Maximum resolution	- pixels
Product color	Black
Housing material	Aluminum

Weight and Dimensions

Depth	162.6 mm
Width	317.5 mm
Height	48.3 mm
Weight	1900 g
