Secure 4/8 port KM Switch User Manual
INSTALLATION
SECTIONS
Table of Contents
1 2 4 5 6 73
Before Installation
Unpacking the Product
Before opening the product packaging, inspect the packaging seal
condition to assure that product was not accessed or tampered during
delivery. If the packaging seal looks suspicious, contact Belkin Technical
Support and do not use the product.
After removing the packaging seal, please inspect packaging content to
verify that required components included as listed in the Package Contents
of this manual.
After the Belkin Secure KM is removed from its packaging materials, inspect
the four tampering-evident labels to assure that product is properly sealed.
If one or more label is damaged or missing, contact Belkin Tech Support
and do not use that product.
Where to place the Switch:
The enclosure of the Switch is designed for desktop or under-the-desk
mount configurations. An optional Mount Kit (Belkin part number F1D006)
is available for the F1DN104K-3. Rack-mount brackets are included with
the F1DN108K-3.
Consider the following when deciding where to place the Switch:
• Access to the front-panel push buttons is not required, since the
switching can be done through the Seamless Cursor Switching (SCS)
interface.
• The lengths of the cables attached to your keyboard and mouse
• The location of your computers in relation to your console
• The lengths of the cables you use to connect your computers
to the Switch
Warning: Avoid placing cables near fluorescent lights, air-conditioning
equipment, or machines that create electrical noise (e.g., vacuum cleaners).
Important:
1. If the unit’s enclosure appears disrupted or if all channel-select LEDs
flash continuously, please remove product from service immediately
and contact Belkin Technical Support at (800) 282-2355.
2. Do not connect switch to computing devices:
a. That are TEMPEST computers;
b. That include telecommunication equipment;
c. That include frame grabber video cards;
d. That include special audio processing cards.

Belkin F1DN104K-3 Specifications

General

Console ports	3.5mm headphone, USB A
Audio connections	Yes
Headphone outputs	1
USB connector type	USB Type-A
Number of computers controlled	4
Built-in display	No
Power source	AC
Input current	1.5 A
AC input frequency	50 - 60 Hz
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Maximum resolution	- pixels
Product color	Black
Housing material	Aluminum

Weight and Dimensions

Depth	162.6 mm
Width	317.5 mm
Height	48.3 mm
Weight	1900 g
