154 MAINTENANCE
LIGHT SOURCES
Replacing the LED light
source
WARNING
Overlooking the vehicle in
traffic due to a defective
light source on the vehicle
Safety risk
Replace defective light
sources as quickly as
possible. For details please
contact a specialist service
facility, preferably an
authorized BMW Motorrad
Retailer.
All light sources on the vehi-
cle are LED light sources. The
service life of the LED light
sources is longer than the as-
sumed service life of the ve-
hicle. If an LED light source is
faulty, please contact a spe-
cialist workshop, preferably an
authorized BMW Motorrad re-
tailer.
TRIM PANEL COMPONENTS
Removing the front-fairing
panel
Pull the front-fairing panel 1
forward by the handle cen-
tered under the windshield for
this purpose.
Detach the front-fairing
panel 1 from the detents 2.
Remove the front-fairing
panel 1 in the forward
direction.
Installing the front-fairing
panel
Position front-fairing panel 1
in arrow direction.
Feed in front-fairing panel 1
using the guides 3 and 4.

BMW CE 04 Specifications

General

Motor Power	31 kW (42 hp)
Battery Capacity	8.9 kWh
Top Speed	120 km/h (75 mph)
Rated Power	15 kW (20 hp)
Front Suspension	Telescopic fork
Rear Suspension	Single-sided swing arm
ABS	Standard
Traction Control	Standard
Wheelbase	1, 675 mm (65.9 inches)
Range	130 km
Charging Time	4 hours 20 minutes (0-100%)
Seat Height	780 mm
Motor Type	Liquid-cooled electric motor
Front Brake	Twin disc brake
Rear Brake	Single disc brake
Torque	62 Nm
Length	2, 285 mm
Width	855 mm
Height	1, 150 mm
Weight	231 kg
