BMW F700 gs User Manual

Remove air filter 3.
Install air filter
Install air filter 3.
Place air filter cover 2 in posi-
tion, easing the side trim pan-
els out slightly to do so.
Install screws 1 with the wash-
ers.
Installing centre trim panel
( 113).
Jump starting
The wires leading to the
power socket do not have
a load-capacity rating adequate
for jump-starting the engine. Ex-
cessively high current can lead
to a cable fire or damage to the
vehicle electronics.
Do not use the on-board socket
to jump-start the engine of the
motorcycle.
A short-circuit can res-
ult if the crocodile clips
of the jump leads are accident-
ally brought into contact with the
motorcycle.
Use only jump leads fitted with
fully insulated crocodile clips at
both ends.
Jump-starting with a donor-
battery voltage higher than
12 V can damage the vehicle
electronics.
Make sure that the battery of the
donor vehicle has a voltage rating
of 12 V.
Removing centre trim panel
( 112).
When jump-starting the engine,
do not disconnect the battery
from the on-board electrical
system.
9
114
z Maintenance

BMW F700 gs Specifications

General

Displacement	798 cc
ABS	Standard
Fuel System	Electronic fuel injection
Engine Type	Liquid-cooled, 4-stroke, in-line two-cylinder
Max Power	75 hp (55 kW) at 7, 300 rpm
Max Torque	77 Nm @ 5, 300 rpm
Transmission	6-speed
Fuel Capacity	16 liters
Seat Height	820 mm (32.3 inches)
Wet Weight	209 kg (461 lbs)
Front Suspension	Telescopic fork, 41 mm
Rear Suspension	Cast aluminum dual swing arm, central spring strut
Front Brake	Dual 300 mm discs, 2-piston floating calipers
Rear Brake	Single 265 mm disc, single-piston floating caliper
Dry Weight	186 kg
