BMW F700 gs User Manual

Installing battery
If the battery was discon-
nected from the motorcycle
for a prolonged period of time
it will be necessary to enter the
current date in the instrument
panel, in order to ensure that the
service-due indicator functions
correctly.
If you want to have the date
set consult a specialist work-
shop, preferably an authorised
BMW Motorrad dealer.
Switch off the ignition.
Insert the battery into the bat-
tery compartment, with the
positive terminal on the right
in the direction of travel.
Place the battery holder in po-
sition, making sure that the
leads are correctly routed at
position 4.
Install screws 3 on left and
right.
Installation in the wrong
sequence increases the risk
of short-circuits.
Always proceed in the correct
sequence.
Connect positive lead 2 to the
battery's positive terminal.
Connect negative lead 1 to the
battery's negative terminal.
Installing centre trim panel
( 113).
Setting clock ( 35).
9
118
z Maintenance

BMW F700 gs Specifications

General

Displacement	798 cc
ABS	Standard
Fuel System	Electronic fuel injection
Engine Type	Liquid-cooled, 4-stroke, in-line two-cylinder
Max Power	75 hp (55 kW) at 7, 300 rpm
Max Torque	77 Nm @ 5, 300 rpm
Transmission	6-speed
Fuel Capacity	16 liters
Seat Height	820 mm (32.3 inches)
Wet Weight	209 kg (461 lbs)
Front Suspension	Telescopic fork, 41 mm
Rear Suspension	Cast aluminum dual swing arm, central spring strut
Front Brake	Dual 300 mm discs, 2-piston floating calipers
Rear Brake	Single 265 mm disc, single-piston floating caliper
Dry Weight	186 kg
