BMW F700 gs User Manual

Fuel expands when hot.
Fuel escaping from an
overfilled tank could make its way
onto the road surface. This could
cause a fall.
Do not overfill the fuel tank.
Fuel attacks plastics, which
become dull or unsightly.
Wipe plastic parts immediately
after contact with fuel.
Make sure the ground is level
and firm and place the motor-
cycle on its side stand.
The volume of the tank can
be utilised to the full only
when the motorcycle is propped
on its side stand.
Open the protective cap.
Use the ignition key to unlock
the fuel filler cap and pop the
cap open.
Do not fill the tank past the
bottom edge of the filler neck.
If filling occurs after the fuel
level has gone below the
reserve limit, the amount filled
must be greater than the reserve
amount for the new fuel level to
be recognised and the warning
light to switch off.
The “usable fuel capacity”
specified in the technical
data is the quantity that the fuel
tank could hold if it had been run
dry and the engine had cut out
due to a lack of fuel.
Usable fuel capacity
approx. 16 l
Reserve fuel
min 2.7 l
Press the fuel tank cap down
firmly to close.
6
73
z Riding

BMW F700 gs Specifications

General

Displacement	798 cc
ABS	Standard
Fuel System	Electronic fuel injection
Engine Type	Liquid-cooled, 4-stroke, in-line two-cylinder
Max Power	75 hp (55 kW) at 7, 300 rpm
Max Torque	77 Nm @ 5, 300 rpm
Transmission	6-speed
Fuel Capacity	16 liters
Seat Height	820 mm (32.3 inches)
Wet Weight	209 kg (461 lbs)
Front Suspension	Telescopic fork, 41 mm
Rear Suspension	Cast aluminum dual swing arm, central spring strut
Front Brake	Dual 300 mm discs, 2-piston floating calipers
Rear Brake	Single 265 mm disc, single-piston floating caliper
Dry Weight	186 kg
