BMW K 1200 S User Manual

Remove screw 1.
Pull lamp housing on screw
connection side out of turn
indicator housing.
Press bulb 2 into fitting 3
and remove it by turning it
counterclockwise.
Remove bulb 2 from bulb
holder.
Install bulb in reverse order.
Use a clean, dry cloth to
hold new bulb.
Jump starting
The wires leading to the
onboard socket do not
have a load-capacity rating
adequate for jump-starting
the engine. Excessively high
current can lead to a cable
fire or damage to the motor-
cycle electronics.
Do not use the onboard sock-
et to jump-start the motorcy-
cle.
Touching live parts of
the ignition system with
the engine running can cause
electric shock.
Do not touch parts of the igni-
tion system when the engine
is running.
A short-circuit can result
if the crocodile clips of
the jump leads are acciden-
tally brought into contact with
the motorcycle.
Use only jump leads fitted
with fully insulated crocodile
clips at both ends.
Jump-starting with a
donor-battery voltage
higher than 12 V can damage
the motorcycle electronics.
The battery of the donor ve-
7
115
z Maintenance

BMW K 1200 S Specifications

General

Displacement	1157 cc
Transmission	6-speed
Dry Weight	227 kg (500 lbs)
Final Drive	Shaft
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Power	167 hp (123 kW) @ 10, 250 rpm
Torque	130 Nm (96 lb-ft) @ 8, 250 rpm
Fuel Capacity	5.0 gallons (19 liters)
Seat Height	820 mm (32.3 inches)
Frame	Aluminum bridge frame
Front Suspension	BMW Duolever
Rear Suspension	BMW Paralever
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, 2-piston caliper
Wheelbase	1, 571 mm (61.9 inches)
