BMW K 1200 S User Manual

Tripmeter 2 (Trip II)
Residual range
Resetting tripmeter
Switch on ignition.
Select desired tripmeter.
Press and hold Tripmas-
ter button 1 until display
changes.
Tripmeter is reset to zero.
Residual range
The residual operating
range 1 is displayed together
with the lettering
RANGE only
after the reserve fuel level
is reached. It is calculated
on the basis of your style
of riding and the amount of
fuel in the tank; the reading
indicates the estimated
distance you can travel before
the fuel supply runs out.
If the motorcycle is resting
on its side stand, the level in
the tank cannot be measured
correctly, so this estimate of
residual operating range will
be inaccurate.
When refueling, fuel is not
registered by the Tripmas-
ter until the quantity added is
more approx. a gallon (sever-
al liters).
The determined residu-
al range is an approxi-
mate reading. BMW Motorrad
therefore recommends that
you do not try to use the full
residual range before refuel-
ing.
4
42
z Operation

BMW K 1200 S Specifications

General

Displacement	1157 cc
Transmission	6-speed
Dry Weight	227 kg (500 lbs)
Final Drive	Shaft
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Power	167 hp (123 kW) @ 10, 250 rpm
Torque	130 Nm (96 lb-ft) @ 8, 250 rpm
Fuel Capacity	5.0 gallons (19 liters)
Seat Height	820 mm (32.3 inches)
Frame	Aluminum bridge frame
Front Suspension	BMW Duolever
Rear Suspension	BMW Paralever
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, 2-piston caliper
Wheelbase	1, 571 mm (61.9 inches)
