Close the lock straps.
Press the lock straps
against the case body.
The case volume is adapted
to the contents.
Removing case
Turn lock barrel in direction
RELEASE.
Pull the black release lever
upwards.
Pull the case out of the up-
per mounting.
Lift the case out of the low-
er mounting.
6
87
z Accessories

BMW K 1200 S Specifications

General

Displacement	1157 cc
Transmission	6-speed
Dry Weight	227 kg (500 lbs)
Final Drive	Shaft
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Power	167 hp (123 kW) @ 10, 250 rpm
Torque	130 Nm (96 lb-ft) @ 8, 250 rpm
Fuel Capacity	5.0 gallons (19 liters)
Seat Height	820 mm (32.3 inches)
Frame	Aluminum bridge frame
Front Suspension	BMW Duolever
Rear Suspension	BMW Paralever
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, 2-piston caliper
Wheelbase	1, 571 mm (61.9 inches)
