figure for residual range possible
with the fuel remaining in the fuel
tank to the Navigator, so it is no
longer necessary to enter this
value.
Time and date
The Navigator sends time and
date to the motorcycle. Accept-
ance of these data for the read-
ings on the instrument panel has
to be activated in the user set-
tings for the motorcycle.
Security settings
The BMW Motorrad Navigator
IV can be secured against unau-
thorised use with a four-digit PIN
(Garmin Lock). If this function is
activated, while the Navigator is
cradled on the motorcycle and
the ignition is switched on you
are prompted to add the mo-
torcycle to the list of secured
vehicles. If you answer "Yes" at
this prompt the Navigator saves
the VIN of this vehicle in its in-
ternal memory.
A maximum of five VINs can be
saved in this way.
Subsequently, the PIN does not
have to be entered when the
Navigator is switched on by ig-
nition ON while cradled in any of
these vehicles.
If the Navigator is removed from
the vehicle while switched on, a
security prompt asking for the
PIN to be entered is issued.
Screen brightness
Screen brightness is adjusted by
the motorcycle while the unit is
cradled. There is no provision for
manual input.
Cases
Open cases
with central locking system
OE
If applicable, open the central
locking.
Turn the key to the in the case
lock to the position indicated
by the dot.
Push lock barrel 1 down.
Lever 2 pops up.
7
122
z Accessories

BMW K1600GTL Specifications

General

Displacement	1649 cc
ABS	Standard
Traction Control	Standard
Suspension Front	BMW Motorrad Duolever
Suspension Rear	BMW Motorrad Paralever
Tires Front	120/70 ZR 17
Tires Rear	190/55 ZR 17
Engine Type	Oil/water-cooled, six-cylinder, four-stroke, in-line engine
Power	118 kW (160 hp) at 7, 750 rpm
Torque	175 Nm at 5250 rpm
Transmission	6-speed
Fuel Capacity	26.5 liters
Seat Height	750 mm
Brakes Front	Dual 320 mm discs, 4-piston calipers
Brakes Rear	Single 320 mm disc, 2-piston caliper
Weight	358 kg (unladen weight, road ready, fully fueled)
