BMW K1600GTL User Manual

Installing seat
Connect plug 2 of the seat
heating.
Position the seat with
mounts 3 in rubber buffers 4
on left and right.
Lower the rear of the seat and
engage the seat in the latching
mechanism.
Windscreen
Adjusting windscreen
Switch on the ignition.
When you pull away the wind-
screen automatically returns to
the position it was in before the
ignition was switched off.
Press top section of button 1
to raise the windscreen.
Press bottom section of but-
ton 1 to lower the windscreen.
Switch off the ignition.
The windscreen automatically
moves to the bottom limit posi-
tion.
If the windscreen encounters
resistance before it reaches
its limit position the pressure-
sensitive finger guard system
goes active. The windscreen
is stopped and raised slightly.
After a delay of a few seconds
the windscreen again attempts
to move to the bottom limit
position.
There is no guarantee that the
pressure-sensitive finger guard
system will function correctly if a
windscreen that does not have
BMW approval is installed.
Under these circumstances:
Before switching off the igni-
tion always check that there is
nothing to obstruct movement
of the windscreen.
4
72
z Operation

BMW K1600GTL Specifications

General

Displacement	1649 cc
ABS	Standard
Traction Control	Standard
Suspension Front	BMW Motorrad Duolever
Suspension Rear	BMW Motorrad Paralever
Tires Front	120/70 ZR 17
Tires Rear	190/55 ZR 17
Engine Type	Oil/water-cooled, six-cylinder, four-stroke, in-line engine
Power	118 kW (160 hp) at 7, 750 rpm
Torque	175 Nm at 5250 rpm
Transmission	6-speed
Fuel Capacity	26.5 liters
Seat Height	750 mm
Brakes Front	Dual 320 mm discs, 4-piston calipers
Brakes Rear	Single 320 mm disc, 2-piston caliper
Weight	358 kg (unladen weight, road ready, fully fueled)
