BMW S 1000XR User Manual

Remove the seat ( 94).
ATTENTION
Battery not disconnected in
accordance with correct pro-
cedure
Risk of short-circuit
Always proceed in compliance
with the specified disconnec-
tion sequence.
First disconnect negative bat-
tery cable 1.
Then disconnect positive bat-
tery cable 2.
Connecting battery to
motorcycle
First connect positive battery
cable 2.
Then connect negative battery
cable 1.
Install the seat ( 94).
Removing battery
Remove the seat ( 94).
Disconnecting battery from
motorcycle ( 182).
Remove screws 1.
Disengage holder 2 from
bracket 3 and remove.
Lift battery 4 up and out; work
it slightly back and forth if it is
difficult to remove.
Installing battery
NOTICE
If the vehicle has been discon-
nected from the battery for a sig-
nificant time, the current date will
have to be entered in the instru-
ment cluster to guarantee correct
operation of the service display.
9
183
z Maintenance

BMW S 1000XR Specifications

General

Displacement	999 cc
Max Power	165 hp (121 kW) at 11, 000 rpm
Max Torque	114 Nm (84 lb-ft) at 9, 250 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Aluminum composite bridge frame, partially self-supporting engine
Traction Control	Dynamic Traction Control (DTC)
Wheelbase	1, 548 mm (60.9 in)
Seat Height	840 mm (33.1 in)
Dry Weight	226 kg (498 lbs)
Fuel Capacity	20 l (5.3 gal)
Rear Suspension	Aluminum swing arm, central spring strut
Front Brakes	Twin disc, 320 mm, 4-piston radial calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
ABS	BMW Motorrad ABS Pro
