Installation
1. Insert the wind deflector 1 into the holders 2
on the rollover bars; the arrow should point
in the direction of travel.
2. Push the wind deflector down, arrow 1, and
then push down and forward simultane‐
ously, arrow 2, until it engages.
Attach the wind deflector securely
The wind deflector must engage firmly;
otherwise, it could become detached at higher
vehicle speeds.◀
Removing
1.
Push the wind deflector down and back si‐
multaneously, arrow 1, to disengage it from
the catch mechanism.
2. Pull the wind deflector upward out of the
holders, arrow 2.
Clothes hooks
Coat hooks 1 are located on the wind deflector
panels in the rollover bars.
Only hang light objects on the hooks
Do not hang heavy objects on the hooks;
otherwise, they could endanger the passengers,
such as during braking or evasive maneuvers.◀
Storage
Fold the wind deflector 1 and slide it into the
storage pouch 2.
The wind deflector can be stored on the lateral
storage shelf behind the seats.
Seite 35
Opening and closing Controls
35
Online Edition for Part no. 01 40 2 609 184 - 09 11 500
