16 en | Introduction
AMC2 Modular
Controller
2018-09 | AMC2-4W_UL | Bosch Access Systems GmbH
The setup procedure for an AMC2-4W is made very simple and
fast by the use of door templates. Once selected, all the inputs
and outputs are predefined. These settings can be changed to
choose every free contact of the controller or a connected
extension.
Notice!
The use of the burglar alarm was not evaluated by UL.
Consequences
3.2 Equipment Configuration
Figureî3.3: Upper circuit board with display (top side)
1 (N.A.)
2 DIL switch for RS-485 address selection, protocol . These
host interfaces are not used for UL installations.
3 Lithium battery for buffering of static RAM and real time
clock (RTC). The battery life is estimated at 10 years,
nevertheless an error message is generated if the voltage
sinks below a preset minimum level.
