Bosch APC-AMC2-4WCF User Manual

AMC2 Modular
Controller
Installing | en 23
Bosch Access Systems GmbH 2018-09 | AMC2-4W_UL |
4 Installing
Notice!
To build a UL listed configuration, refer to UL Requirements,
page 45
4.1 Mounting
The AMC2-4W can be attached on a standard 35mm (1.377in.)
mounting rail using a snap-in mechanism. Attach the AMC2-4W
into the upper edge of the mounting rail [1], then push down
the device and snap it onto the rail by pushing it towards the
back [2].
Figure4.1: Mounting the AMC2 on a mounting rail

Bosch APC-AMC2-4WCF Specifications

General

Brand	Bosch
Model	APC-AMC2-4WCF
Category	Controller
Language	English
