20 en | Introduction
AMC2 Modular
Controller
2018-09 | AMC2-4W_UL | Bosch Access Systems GmbH
3.3 Performance Characteristics
– Intelligent access manager for 1 - 4 entrances (for example,
doors, man traps, barriers)
– Host address selectable using DIL sliding switch
– Ethernet host interface
– Four peripheral input devices using Wiegand interface
– Eight relay outputs
– voltage free, power is supplied externally (dry mode)
– powered by internal power supply (wet mode)
– Eight analog inputs with internal power supply
– Battery buffered SRAM and real time clock (RTC)
– Pluggable Compact Flash card
– Liquid Crystal Display
– Transfer rate host interface Ethernet: 10/100 Mbit/s
– Transfer rate to the extension interface: 9,6 kBit/s
– Self regulating transmit/receive switching
– Tamper contact for external covers
– Power supply: 10 V to 14 Vdc, max. 3 A
– Tamper contact for external covers
Notice!
For UL installations, the Bosch APS-PSU-60 power supply may
be used, and must be located in the same room as the
connected AMC2 device. Recommended maximum distance
between power supply unit and AMC2 is 3 m (9.84 ft).
