Appendices | en 63
Bosch Access Systems GmbH 2018-09 | AMC2-4W_UL |
8 Appendices
Notice!
To build a UL listed configuration, refer to UL Requirements,
page 45
8.1 Connecting Diagrams
Figure8.1: Connectors on upper PCB
1 TXD+
2 TXD-
3 RXD+
4 not connected
5 not connected
6 RXD-
7 not connected
8 not connected
Tab.8.2: Ethernet Network socket (RJ45)
