Bosch Nyon Operating Instructions

English – 10
1 270 020 Wen | (13.5.16) Bosch eBike Systems

10 Operating unit
11 Joystick on the operating unit
12 “Home” button on the operating unit
13 Decrease assistance level button
14 Increase assistance level button
15 Holder for operating unit
16 Button push/start aid “WALK”
17 Lock latch for on-board computer
18 Locking screw for on-board computer
WALKWA L K
WALKWA L K
15
16
13
12
14
11
4
3
17
18
10
