NOTICE
Failure of the product due to overheating
To avoid overheating and to ensure a smooth operation of the product,
sufficient air has to circulate according to the minimum distances specified,
see ⮫ Chapter 10.2 “Installation notes” on page 24.
This is a product that corresponds to the limit values of the emitted interference of class A
(industrial environments). This is a product that does not correspond to the limit values of the
emitted interference of class B (residential area and small enterprises.
When using the product in residential areas or small enterprises, the operator has to take
actions to prevent radio interferences (also refer to DIN EN 55022).
7 Technical data
7.1
General technical data
COREX-C-X2 COREX-C-X3 COREX-M-C3
Processor Zync Ultrascale+,
64 bit, 4 × ARM A53
Zync Ultrascale+,
64 bit, 4 × ARM A53
Zync Ultrascale+,
64 bit, 4 × ARM A53
RAM 2 GByte DRAM 2 GByte DRAM 2 GByte DRAM
Internal physical read-
only memory (eMMC)
4 GByte, also refer to
⮫ Chapter 5.6 “Wear
parts” on page 11
4 GByte, also refer to
⮫ Chapter 5.6 “Wear
parts” on page 11
4 GByte, also refer to
⮫ Chapter 5.6 “Wear
parts” on page 11
Internal non-volatile
random-access memory
(NVRAM)
1 Mbyte 1 Mbyte 1 Mbyte
Extensions None None Multi-Ethernet
and ctrlX I/O
Communication inter-
faces
RJ-45
• 2 × Ethernet connec-
tion (10 Mbit, 100
Mbit, 1 Gbit)
RJ-45
• 3 × Ethernet connec-
tion (10 Mbit, 100
Mbit, 1 Gbit)
RJ-45
• 3 × Ethernet connec-
tion (10 Mbit, 100
Mbit, 1 Gbit)
• 2 × Ethernet connec-
tion (10 Mbit, 100
Mbit)
USB Not enabled 1 × USB host, TYPE C
(USB2.0), maximum
cable length of 3 m
1 × USB host, TYPE C
(USB2.0), maximum
cable length of 3 m
SD card Slot for SD card Slot for SD card Slot for SD card
Battery CR1025 CR1025 CR1025
Weight 314 g 314 g 346 g
Dimensions Refer to ⮫ Chapter 10.1
“Housing dimensions”
on page 23
Refer to ⮫ Chapter 10.1
“Housing dimensions”
on page 23
Refer to ⮫ Chapter 10.1
“Housing dimensions”
on page 23
