No. Name Connection type Connector type
(integrated)
Mating connector and cable
(From outside)
X2 X3 X3
PLUS
➃
XF51 Ethernet
10/100/1000 MBit
1G Bit/s Ethernet (configurable)
TSN-capable (Time-Sensitive Networking)
RJ45 socket
8-pin
RJ45 plug
(twisted pair, 8-wire)
‒ ✓ ✓
➄
CF01 Slot for SD card
‒
SD card
✓ ✓ ✓
➅
XD10 24 V plug, U
L
2-pin 2-pin
✓ ✓ ✓
➆
GB01 Battery case
‒ ‒ ✓ ✓ ✓
➇
XF23 Ethernet
10/100 MBit Ethernet (configurable)
RJ45 socket
8-pin
RJ45 plug
(twisted pair, 4-wire)
‒ ‒ ✓
➈
XF24 Ethernet
10/100 MBit Ethernet (configurable)
RJ45 socket
8-pin
RJ45 plug
(twisted pair, 4-wire)
‒ ‒ ✓
➉
XD10 24 V plug U
L
, U
P
4-pin 4-pin
‒ ‒ ✓
9.1.1
Local bus interface Ethercat of ctrlX CORE
PLUS
X3
The local bus connected to the ctrlX CORE
PLUS
at the right is a 100 MBit/s LVDS Ethercat bus and
the cycle time between 2 ms and 10 ms. The ctrlX CORE
PLUS
can be extended with up to 20 ctrlX
I/O modules. The number of connectable modules depends on the total current consumption of the
ctrlX IO modules. The ctrlX CORE
PLUS
can provide up to 3 A for the current supply of the modules.
The ctrlX CORE
PLUS
supplies the connected I/O modules with the logic voltage U
L
and the periphery
voltage U
P
. The voltages and currents fed in are measured internally and applied to the process data.
For U
L
, only the current consumption of the infeed terminal and the I/O modules. For the integration
into the parent system, the respective ESI files are available. For the ESI files, go to ⮫ http://www.bos-
chrexroth.com/electrics.
Synchronizing the application
The application is synchronized in the "SM synchronous" mode.
