NOTICE
Material damage due to contamination
There is an endcover on the right of the bus coupler upon delivery. Remove
this endcover to connect the modules in series at the bus coupler. Position
the endcover on the last module to protect it against contamination.
Fig. 11: Locking lever to release the clamping of the open position
Each module has to be snapped separately.
10.4 Dismounting the control
For dismounting, use a common tool such a slotted screwdriver with a 2.5 mm blade.
10.4.1 Dismounting steps
NOTICE
Destruction of components and devices due to mounting and dismounting
under voltage!
− Before mounting or dismounting, disconnect the control - including its
components - from voltage.
−
Connect the voltage only after the control and its components have been
set up.
For a secure decommissioning with regard to the IT security, refer to ⮫ Chapter 11.3.1 “Notes on safe
decommissioning” on page 35.
